· Commercial use economical large capacity
· Food grade SUS304 trays and SUS201 stainless steel housing, latches;
· Mechanical control panel with PVC finish and PF knobs.
· Aluminum alloy door handle,Stainless steel with tempered glass window door;
· Upper and Lower Rack Gap 50mm(1.96"),Track Grid Spacing 12mm;Noise Level 65dB
| Model |
RFD-00 |
| Dimension |
880X700X1450mm |
| Power |
5.85kw |
| Voltage |
220V |
| Max.Timing |
15hrs/24hrs |
| Capacity |
24 Trays/100kg/600L |
| Temperature |
40~90℃ (104~194℉) |
| N.W/G.W |
94kgs / 139.5kgs |
| Packing Size |
1020X800X1600mm |
| Track Grid Spacing |
12mm |
| Tray size |
670X670mm |
Motor: Totally enclosed dual ball bearing motor with pure copper coil; 1800r/m motor speed.
Fan Blades: 200mm (8") aluminium alloy fan blades; Fan blade thickness 0.8mm.
Heating Element: 304 stainless steel heating tube with high-density 201 radiating fins.
Thermostat: Intelligent temperature control, temperature control is accurat.
Trays Material: Food grade 304 stainless steel racks.
